OCPP 1.6：Smart Charging
In the OCPP 1.6 protocol, smart charging refers to optimizing the electric vehicle (EV) charging process by dynamically controlling power distribution based on parameters such as grid capacity, energy costs, and user preferences. This functionality is crucial for improving energy efficiency, reducing operational costs, and ensuring grid stability.
▶ Key Features of Smart Charging in OCPP 1.6
1、Charging Profiles:
OCPP 1.6 supports the use of charging profiles, which are power limits set for specific time periods. These profiles allow operators to control the charging behavior of individual stations or an entire network.
For example, a charging profile might specify delivering 10 kW of power for the first 2 minutes and then adjusting to 25 kW for the next 5 minutes. This flexibility helps operators effectively manage energy distribution.
2、SetChargingProfile.req Command:
The central system sends a SetChargingProfile.req message to the charging station to set the charging profile. The request includes parameters such as power or current limits, duration, and time intervals.
The charging station confirms acceptance or rejection of the request via a SetChargingProfile.conf message.
3、Load Balancing：
OCPP 1.6 supports load balancing by distributing available power among multiple charging stations at a site. This prevents grid overload while ensuring fair allocation of resources.
4、State of Charge (SoC) Monitoring:
Although OCPP 1.6 cannot directly request specific energy amounts (e.g., kWh) from vehicles, it can monitor the State of Charge (SoC) of vehicle batteries. Operators can use this data to determine how much additional energy is needed and adjust charging accordingly.
5、Energy Management:
By integrating data from site meters or other sensors, operators can manage peak demand and optimize energy usage across a site. For example, they can reduce charging power during peak demand periods to avoid excessive energy costs.
6、Interoperability：
OCPP 1.6 ensures compatibility between charging stations and management systems from different manufacturers, fostering a unified EV charging ecosystem.
▶ Limitations of Smart Charging in OCPP 1.6
1. Limited Data Exchange Capabilities: Compared to newer versions like OCPP 2.0.1, OCPP 1.6 does not support advanced functionalities such as dynamic load management or direct communication of specific energy requirements (kWh) from EVs.
2. Complex Configuration: Setting up and managing charging profiles via SetChargingProfile.req can be complex due to numerous configuration options, increasing the risk of errors if not implemented correctly.
▶ Practical Applications
Fleet Management: Operators can optimize fleet charging schedules using smart charging profiles to minimize downtime and reduce costs.
Grid Stability: By synchronizing EV charging with grid capacity and demand, operators can alleviate stress on the electrical grid during peak hours.
Cost Optimization: Smart charging helps avoid peak demand charges and leverage off-peak electricity rates to lower energy costs.
Despite its limitations, OCPP 1.6 remains widely adopted due to its robust features and interoperability, making it a cornerstone for global EV infrastructure development. However, due to technical constraints, most charging station manufacturers on the market cannot fully support smart charging functionality. Shenzhen Huizhi’s OCPP protocol gateway fully supports all functions of the OCPP 1.6 protocol, including smart charging capabilities, effectively addressing the shortcomings of many charging station manufacturers.
